型号：
额定载荷Rated Load
15T、20T
额定输出Rated Output
2.0000±0.001MV/V
综合误差Total Error
±0.1%F.S
蠕变Creep(30minutes)
±0.02%F.S
推荐工作电压Recommended Excitation Voltage
5V～12V(AC or DC)
最大工作电压Maximum Excitation Voltage
15V(AC or DC)
零点平衡Zero Balance
±1%F.S
输入阻抗Input Impedance
380±5Ω
输出阻抗Output Impedance
350±2Ω
绝缘阻抗Insulation Impedance
≥5000MΩ
安全过载率Safe Overload
150%F.S
极限过载率Ultimate Overload
200%F.S
工作温度范围Operating Temperature Range
(-30～+70)℃
温度补偿范围Compensated Temperature Range
(-20～+60)℃
输出温度影响Temperature Effect On Load
±0.02%F.S/10℃
零点温度影响Temperature Effect On Zero
±0.02%F.S/10℃
材质Construction
合金钢Alloy Steel
防护等级Protection Class
IP68&IP67
引用标准Citation
GB/T7551-2008/OIML R60
接线方式Mode of Connection
输入+:红 Input+:Red
输入-:绿 Input-: Green
输出+:黄Output+:Yellow
输出-:白 Output-:White
